FACILITIES LIST
EDM
(1) FA 10PS Mitsubishi Wire EDM Submersible Digital Capabilities of 3ra / .002 Dia Wire
(2) DWC 90 Mitsubishi Wire EDMs With 3r Tooling
(2) DWC 90 Mitsubishi Wire EDMs With Fine Finish Capabilities (6ra or better)
(1) 90 SZ Submersible Wire EDM With Fine Finish Capabilities (6ra or better)
(3) Eltee Pulsitron EDMs with Vector Machining Attachments
(1) Current EDM Drill ST300
MILLING
(1) HAAS VF3YT CNC Mill
(1) FEELER UPM-800 CNC Mill
(1) FANUC ROBODRILL D14MIA5 CNC Mill
(2) Two Axis CNC Bridgeport Vertical Mill
(2) Manual Bridgeport Vertical Mill
(2) Three Axis CNC Milltronics Vertical Mill
INSPECTION EQUIPMENT
(1) Ram Optical OMIS 16x12 Inspection Machine
(4) J&L Optical Comparitors with Quadra Check
(2) Mitutoyo PJ-300 P Optical Comparitors
(1) Baush & Lomb Stereo Zoom 4 Microscope
(1) Baush & Lomb Stereo Zoom 5 Microscope
(2) Mitutoyo Tool Maker’s Microscope
(3) Digital Height Gages
Gage Pins in both +/- Tolerances
Grade A Gage Blocks
(3) Starret Cro-Blocks
(3) Webber Carbide
(15) Mitutoyo Ceramic Gage Blocks
TURNING
(1) Mori Seiki TF 2000
CNC Turning Center
8”-10” Swing
2.563 DIA THROAT Through to Chuck
FORM & SURFACE GRINDING
(13) Harig 612 Surface Grinder
(1) Harig 618 Auto Step & Index Grinder
(1) Sharp SG618-3A 3-Axis Grinder
(1) Sharp SG820-3A 3-Axis Grinder
Wide Range of Grinding and Wheel Dressing Fixtures
Large Assortment of Diamond Wheels for Form Grinding Carbide
MISCELLANEOUS FIXTURES & EQUIPMENT
(2) Roll-In Bandsaw
Drill Press
(1) New Bold Grind All Fixture
(2) 3” Excello Magna-sines
(4) Culp Radius Dressers
(3) Hermann Schmidt 5” Magna-sines
(1) Vinco High Precision Dresser
(3) Harig No. 1 Grind All Fixture
OFFICE EQUIPMENT
(5) Dell PC Computers
Shop Management and Accounting Software
Auto Cad 2007 & 2012, Solid Works Viewer
dwg, dxf, pdf, Kodak, print file capabilities
